Child Weight - Forward Facing Harness | 2 years and 25, up to 90 lbs |
---|---|
Child Weight - Booster | 40 - 120 lbs |
Child Standing Height - Forward Facing Harness | 30 - 58" |
Child Standing Height - Booster | 45 - 62" |
Child Seated Shoulder Height - Forward Facing Harness | 12.5 - 20.5" |
Child Seated Shoulder Height - Booster | 15 - 23" |
Product Weight | 25 lbs |
Product Dimensions - Harness Minimum | 19" W x 28" H x 21" D |
Product Dimensions - Harness Maximum | 19" W x 36" H x 21" D |
Product Dimensions - Booster Minimum | 19" W x 28" H x 21" D |
Product Dimensions - Booster Maximum | 19" W x 36" H x 21" D |
Seating Compartment Height | 23.5" |
Seat Area Depth / Width | 13.5" / 12" |
Shoulder Width | 15.5" |
Harness Slot Heights | 12.5" / 13.5" / 14.5" / 15.5" / 16.5" / 17.5" / 18.5" / 19.5" / 20.5" |
Buckle Strap Depths | 7.0" / 9.0" |
*Recommendation | Britax strongly recommends that children should be secured with a harness system until they exceed the weight or height limits specified. |
